Double flanged Plasma Micro electrostatic cleaner for FCU Air disinfection and sterilization help to fight with covid-19

Certification
Good quality Commcial PHT UVC Air filter for sales
Good quality Commcial PHT UVC Air filter for sales
when i see you first time, Simon, i believe we will have some business with you.And i like your water fan coil and your VRF air conditioner units.

—— Nassif-Lebanon

China Aire Acondicionado Piso Techo fabrica DEKON,Mejor equipos aires acondicionados en China.

—— JOSE

we have the request for water fan coil full range and DEKON made all these for us, and in CKD form, it is not easy to find such ono factory in China.

—— David

I'm Online Chat Now

Double flanged Plasma Micro electrostatic cleaner for FCU Air disinfection and sterilization help to fight with covid-19

China Double flanged Plasma Micro electrostatic cleaner for FCU Air disinfection and sterilization help to fight with covid-19 supplier
Double flanged Plasma Micro electrostatic cleaner for FCU Air disinfection and sterilization help to fight with covid-19 supplier Double flanged Plasma Micro electrostatic cleaner for FCU Air disinfection and sterilization help to fight with covid-19 supplier Double flanged Plasma Micro electrostatic cleaner for FCU Air disinfection and sterilization help to fight with covid-19 supplier Double flanged Plasma Micro electrostatic cleaner for FCU Air disinfection and sterilization help to fight with covid-19 supplier Double flanged Plasma Micro electrostatic cleaner for FCU Air disinfection and sterilization help to fight with covid-19 supplier Double flanged Plasma Micro electrostatic cleaner for FCU Air disinfection and sterilization help to fight with covid-19 supplier

Large Image :  Double flanged Plasma Micro electrostatic cleaner for FCU Air disinfection and sterilization help to fight with covid-19

Product Details:

Place of Origin: made in china
Brand Name: DEKON or OEM
Certification: CE, ISO,AHRI
Model Number: air duct plasma

Payment & Shipping Terms:

Minimum Order Quantity: 5PCS/MODEL
Price: To be discussed by mail
Packaging Details: Standard Export packig
Delivery Time: 25-35days since deposit date
Payment Terms: TT,LC
Supply Ability: 5000pcs per month
Minimum Order Quantity: 50pcs
Contact Now
Detailed Product Description

Double flanged plasma Micro electrostatic air cleaner for Fan coil

Air disinfection and sterilization help to fight with covid-19



Electric field module, i.e. electrically charged module, produces a 10000 V electrostatic
field between the discharge electrodes, so that particulate matters passing through the electric field
are instantly charged. The module adopts negative electrode discharge and generates abundant
negative ions in this process, thereby making the air healthy and fresh.



The phalanx of approx. 1 mm staggered micro-cavities made of special dielectric graphene forms
a micro electrostatic matrix–a strong electric field which applies enormous attraction to charged
fine particles in the air; with only a small air flow impedance produced, it can adsorb almost 100%
of moving particles in the air and the removal efficiency of PM2.5 and other particulate pollutants
is especially outstanding.



Double flanged Plasma Micro electrostatic cleaner for FCU Air disinfection and sterilization help to fight with covid-19



Double flanged Plasma Micro electrostatic cleaner for FCU Air disinfection and sterilization help to fight with covid-19

Double flanged Plasma Micro electrostatic cleaner for FCU Air disinfection and sterilization help to fight with covid-19



Double flanged Plasma Micro electrostatic cleaner for FCU Air disinfection and sterilization help to fight with covid-19


Core advantages:

Ultra-high PM2.5 purification efficiency up to 98% (honeycomb structure significantly enhances
the dust holding capacity and purification efficiency)

Purification efficiency of particulate matters up to 99%; sterilization of bacteria, virus and other
microorganisms

No secondary pollution (the micro electrostatic filter is repeatedly washable and requires no
replacement)

Safe (no exposed high-voltage electrodes, no breakdown spark, no potential safety hazards)

Reduced energy consumption of the system, more energy-efficient (air resistance <10 Pa;
protection of fan coils and air handling units)

Functions:

Ultra-high PM2.5 purification efficiency up to 98%

Purification efficiency of particulate matters in the air up to 99%

Purification efficiency of bacteria, virus and other microorganisms up to 95%



Double flanged Plasma Micro electrostatic cleaner for FCU Air disinfection and sterilization help to fight with covid-19

Double flanged Plasma Micro electrostatic cleaner for FCU Air disinfection and sterilization help to fight with covid-19

Double flanged Plasma Micro electrostatic cleaner for FCU Air disinfection and sterilization help to fight with covid-19




Applications:

Medical systems: hospitals, pharmaceutical factories, operating rooms, isolation wards, blood
stations, rehabilitation centers, etc.;

Workshops: electronics factories, optics factories, plastic and hardware coating factories,
cosmetics factories, food factories, sanitary ware shops;

Office buildings: telecommunications, government office buildings, banks, etc.;

Public places: stations, airports, hotels, beauty salons, tea houses, supermarkets, libraries,
exhibition halls, etc.;

Places of installation: mainly including fan coils, air handling units, ducts of central air
conditioning units, etc.







Specifications

Power supply/frequency: 220 V/50 Hz; discharge voltage: 4000-8000V

Power : 5-10W

Filtration efficiency: PM2.5: 98%; particulate matters: 99%; bacteria, virus and other microorganisms: 95%

Air resistance Pa: 5-12-20 Pa (air speed 0.5-1-1.5 m/s)

Working status indicator: Power indicator, operation indicator, cleaning indicator

Controls : Air flow sensor, linkage, power OFF switch (additional functions)

Remarks : Special specifications can be customized according to customer requirements.



Air Disinfection Products Ranges:

PHT UVC Kit for AHU UV Germicidal 254nm UV air disinfection and sterilization for air handling units to fight with covid PHT UVC Kit for AHU UV Germicidal 254nm UV air disinfection and sterilization for air handling units to fight with covid
UVC Kit for mini split air conditioner-Version R
- LED strips (with UVA 8pcs and UVC 2pcc)
-With wireless remote control
- Four TiO₂ photocatalysis film and film protector
UVC Kit for mini split air conditioner-Version F
- LED strips (with UVA 8pcs and UVC 2pcc)
-With smart App control, panel control and remote control.
- Four TiO₂ photocatalysis film and film protector
PHT UVC Kit for AHU UV Germicidal 254nm UV air disinfection and sterilization for air handling units to fight with covid PHT UVC Kit for AHU UV Germicidal 254nm UV air disinfection and sterilization for air handling units to fight with covid
Plug-in PHT UVC Kit for air ventilation duct - UVC tube 254nm 5W-8W-15W
- Push button control
- Photocatalysis mesh filter
PHT UVC Kit & Filter fr air ventilation duct Flange mounting design, dimention according to request. - UVC tube 254nm, qty and capacity according to actual dimention.
- Active carbon filter
- Photocatalysis mesh filter
PHT UVC Kit for AHU UV Germicidal 254nm UV air disinfection and sterilization for air handling units to fight with covid PHT UVC Kit for AHU UV Germicidal 254nm UV air disinfection and sterilization for air handling units to fight with covid
PHT UVC Kit for FCU. - UVC tube 254nm
- Photocatalysis mesh filter
PHT UVC Kit for AHU. Flange mounting design, dimention according to request. - UVC tube 254nm, qty and capacity according to actual dimention.
- Active carbon filter optional.
- Photocatalysis mesh filter
PHT UVC Kit for AHU UV Germicidal 254nm UV air disinfection and sterilization for air handling units to fight with covid PHT UVC Kit for AHU UV Germicidal 254nm UV air disinfection and sterilization for air handling units to fight with covid
PLASMA MICRO ELECROSTATIC KIT For Fan Coil Units Air Return Side Single Flange Type; Include Shell, core filter module, control. Size can be designed to fit fan coil air return,thickness has 60mm and 90cm two types. PLASMA MICRO ELECROSTATIC KIT For Air handling unit Air Return Side Single Flange Type; Include Shell, core filter module, control. Size can be designed to fit AHU,thickness has 60mm and 90cm two types.
PHT UVC Kit for AHU UV Germicidal 254nm UV air disinfection and sterilization for air handling units to fight with covid PHT UVC Kit for AHU UV Germicidal 254nm UV air disinfection and sterilization for air handling units to fight with covid
PLASMA MICRO ELECROSTATIC KIT For rooftop units, AHU Air Return Side Include Shell, core filter module, control. Size can be designed to fit,thickness has 60mm and 90cm two types. PLASMA MICRO ELECROSTATIC KIT Ceiling concealed cassette type. Plasma filter thickness has 60mm and 90cm two types.
PHT UVC Kit for AHU UV Germicidal 254nm UV air disinfection and sterilization for air handling units to fight with covid PHT UVC Kit for AHU UV Germicidal 254nm UV air disinfection and sterilization for air handling units to fight with covid
KAPHOEU CX-03
Autocar air UVC Kit with carbon filter -Air purifier and Sterilizer
KAPHOEU CX-13
Autocar air UVC Kit with HEPA filter-Air purifier and Sterilizer
PHT UVC Kit for AHU UV Germicidal 254nm UV air disinfection and sterilization for air handling units to fight with covid PHT UVC Kit for AHU UV Germicidal 254nm UV air disinfection and sterilization for air handling units to fight with covid
PHOEU Serie CX-01
Table top UVC Kit with H11 HEPA filter-Air purifier and Sterilizer
P12 CADR 120 m³/h With UVC Lamp and HEPA Filter.-Air purifier and Sterilizer
PHT UVC Kit for AHU UV Germicidal 254nm UV air disinfection and sterilization for air handling units to fight with covid PHT UVC Kit for AHU UV Germicidal 254nm UV air disinfection and sterilization for air handling units to fight with covid
P30 Series -Air purifier and Sterilizer
310 m³/h Prefilter+HEPA H13 Filter+Carbon filter+photocatalysis filter+UVC lamp+ANION PM2.5 data display optional, APP smart control optional.
Big Eye Series -Air purifier and Sterilizer
210 m³/h & 310 m³/h & 465 m³/h Prefilter+HEPA H 13 Filter+Carbon filter+photocatalysis filter+UVC lamp+ANION Air quality display.
PHT UVC Kit for AHU UV Germicidal 254nm UV air disinfection and sterilization for air handling units to fight with covid PHT UVC Kit for AHU UV Germicidal 254nm UV air disinfection and sterilization for air handling units to fight with covid
P50 -Air purifier and Sterilizer
550 m³/h Prefilter+HEPA H13 Filter+Carbon filter+photocatalysis filter+UVC lamp+ANION PM2.5 data display, dual display
P60 -Air purifier and Sterilizer
630 m³/h Prefilter+HEPA H13 Filter+Carbon filter+photocatalysis filter+UVC lamp+ANION=Double sides two sets of filtration
