Water chilled Universal stand type Fan coil units 200CFM 2 TUBES-(FP-34U)

China Water chilled Universal stand type Fan coil units 200CFM 2 TUBES-(FP-34U) supplier
Water chilled Universal stand type Fan coil units 200CFM 2 TUBES-(FP-34U) supplier Water chilled Universal stand type Fan coil units 200CFM 2 TUBES-(FP-34U) supplier

Large Image :  Water chilled Universal stand type Fan coil units 200CFM 2 TUBES-(FP-34U)

Product Details:

Place of Origin: China
Brand Name: Dekon, EKON or OEM brand
Certification: CE

Payment & Shipping Terms:

Price: To be discussed by mail
Packaging Details: Standard Export packig
Delivery Time: 25-35days since deposit date
Payment Terms: TT,LC
Supply Ability: 5000pcs per month
Minimum Order Quantity: 50
Contact Now
Detailed Product Description



model FP-34U FP-51U FP-68U FP-85U
power supply 220V,50Hz,1Ph
air volume H m3/h 340 510 680 850
M 260 390 510 640
L 170 260 340 430
cooling capacity TH H W 1800 2700 3600 4500
BTU/h 6142 9212 12283 15354
SH W 1368 2052 2736 3420
BTU/h 4668 7001 9335 11669
TH M W 1494 2242 2989 3736
SH W 1181 1771 2362 2952
TH L W 1162 1744 2325 2906
SH W 953 1430 1907 2383
heating capacity H W 2700 4050 5400 6750
M W 2131 3197 4262 5328
L W 1675 2511 3349 4186
noise H 0Pa dB(A) 37 39 41 43
power input H 0Pa W 37 52 62 76
waterflow volume   m3/h 0.31 0.46 0.62 0.77
water pressure dropping kPa 7 15 18 23
dimension of water(in & out)connection pipe in ZG3/4" ZG3/4" ZG3/4" ZG3/4"
out ZG3/4" ZG3/4" ZG3/4" ZG3/4"
coil type high efficient copper pipe to wear Hydrophilic aluminum coil
Maximum working pressure Mpa 1.6 1.6 1.6 1.6
