model(4 tube system) | FP-102CA-K4 | FP-136CA-K4 | FP-170CA-K4 | FP-204CA-K4 | FP-238CA-K4 | FP-272CA-K4 | |||
air volume | H | m3/h | 1020 | 1360 | 1700 | 2040 | 2380 | 2720 | |
M | 850 | 1110 | 1400 | 1670 | 1950 | 2150 | |||
L | 680 | 860 | 1100 | 1300 | 1520 | 1600 | |||
static pressure | Pa | 0 | 0 | 0 | 0 | 0 | 0 | ||
cooling capacity | TH | H | W | 4200 | 5600 | 7000 | 8400 | 9850 | 11200 |
BTU/h | 14330 | 19107 | 23884 | 28661 | 33608 | 38214 | |||
SH | W | 3217 | 4200 | 5250 | 6300 | 7350 | 8400 | ||
BTU/h | 10976 | 14330 | 17913 | 21496 | 25078 | 28660 | |||
TH | M | W | 3570 | 4760 | 5950 | 7140 | 8355 | 9520 | |
SH | W | 2499 | 3332 | 4165 | 4998 | 5850 | 6664 | ||
TH | L | W | 3150 | 4200 | 5250 | 6300 | 7347 | 8400 | |
SH | W | 1998 | 2667 | 3333 | 4009 | 4663 | 5334 | ||
heating capacity | H | W | 3240 | 4320 | 5400 | 6480 | 7200 | 8640 | |
M | W | 2620 | 3489 | 4374 | 5251 | 5832 | 6978 | ||
L | W | 2233 | 2978 | 3726 | 4453 | 4968 | 5956 | ||
noise | H | 0Pa | dB(A) | 45 | 46 | 48 | 50 | 52 | 53 |
power input | H | 0Pa | W | 96 | 134 | 152 | 189 | 228 | 250 |
waterflow volume | Cooling | m3/h | 0.72 | 0.96 | 1.21 | 1.45 | 1.70 | 1.98 | |
waterflow volume | heating | 0.27 | 0.36 | 0.45 | 0.54 | 0.60 | 0.72 | ||
water pressure dropping | cooling | kPa | 21.07 | 22.15 | 25.32 | 26.67 | 29.44 | 31.05 | |
heating | 8.26 | 8.56 | 10.87 | 11.65 | 12.31 | 12.78 | |||
dimension of water(in & out)connection pipe | cooling/heating | ZG3/4" | ZG3/4" | ZG3/4" | ZG3/4" | ZG3/4" | ZG3/4" | ||
ZG3/4" | ZG3/4" | ZG3/4" | ZG3/4" | ZG3/4" | ZG3/4" | ||||
coil | type | high efficient copper pipe to wear Hydrophilic aluminum coil | |||||||
dimension of drain pipe | mm | ¢26 | ¢26 | ¢26 | ¢26 | ¢26 | ¢26 | ||
net dimension | unit | L×W×H mm | 730*730*290 | 730*730*290 | 930*930*290 | ||||
panel | 850*850*45 | 850*850*45 | 1050*1050*45 | ||||||
net weight | unit | kg | 35 | 35 | 41 | 42 | 43 | 44 |
